special machine for servo gate valveis an automatic machine tool with high precision and high efficiency. Equipped with multi-station tower or power tower, the machine tool has a wide range of technological performance, can process linear cylinder, oblique cylinder, arc and a variety of threads, slots, worm and other complex workpieces, with linear interpolation, arc interpolation compensation functions, and in the mass production of complex parts has played a good economic effect.
special machine for servo gate The plane where the valve's two guide rails are located intersects with the ground plane to form an inclined plane, and the Angle is 30, 45, 60, and 75. special machine for servo gate valve's bed is a right triangle. It is obvious that in the case of the same guide width, the X-direction drag plate of the inclined bed is longer than that of the flat bed, and the practical significance of the application in the lathe is that more tool numbers can be arranged. special machine for servo gate valve has a larger cross-sectional area than the flat bed of the same specification, that is, good bending and torsional resistance.
Good stability requires the processing of large parts generally use inclined bed or flat bed inclined guide machine tools, because the corresponding parts of small CNC machine tools are also very large, especially the tower part, the use of inclined guide is to have good stability in gravity to improve the accuracy of the machine tool, in some harsh environments can reflect the best of the inclined machine tool. The oblique machine tool can effectively use space and greatly reduce the plane occupation position of the machine tool. The inclined guide is also easy to concentrate iron chips on the chip removal machine for automatic chip removal. The iron filings under cutting have high heat, and the accumulation on the guide rail will cause the guide rail to be heated and deformed, so that the working accuracy will change, which will lead to the batch scrap of the workpiece in the mass automatic processing process.
The cross-sectional area of the special machine for servo gate valve of CNC lathe customization manufacturers is larger than that of the flat bed of the same specification, that is, the bending and torsional resistance is better. special machine for servo gate valve's tool is to cut down on the diagonal above the workpiece, and the cutting force is basically the same as the direction of gravity of the workpiece, so the spindle runs relatively smoothly, which is not easy to cause cutting vibration. The cutting force generated by the tool and the workpiece is 90 with the gravity of the workpiece, which is easy to cause vibration.
One is that the guide rail does not have to bear all the force, and the 45 or 30 guide rail is not easy to residual iron cutting, and the guide rail will not be scratched by the iron cutting when moving at high speed. And the force surface has an Angle, so that the machine tool is stable under the same material and force, and the inclined bed is cast as a whole, and the toughness is relatively high.
